MS06
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MS06 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MS06 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MS06 |
|---|---|
| Manufacturer | Apex Microtechnology |
| Description | CONN SOCKET SIP 20POS GOLD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.366 | $4.124 | $3.881 | $3.638 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.396 | $3.153 | $3.093 | $3.032 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | MS06 | Manufacturer | Apex Microtechnology |
|---|---|---|---|
| Description | CONN SOCKET SIP 20POS GOLD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10875 pcs | Data sheet | MS06 Drawing |
| Category | Connectors, Interconnects | Type | SIP |
| Termination Post Length | 0.270" (6.86mm) | Termination | Solder |
| Series | Apex Precision Power® | Pitch - Post | 0.100" (2.54mm) |
| Pitch - Mating | 0.100" (2.54mm) | Packaging | Bulk |
| Other Names | 598-1387 598-2048 598-2048-ND |
Operating Temperature | - |
| Number of Positions or Pins (Grid) | 20 (1 x 20) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Polyester, Glass Filled | Features | Closed Frame |
| Contact Resistance | - | Contact Material - Post | Brass |
| Contact Material - Mating | Beryllium Copper | Contact Finish Thickness - Post | 200.0µin (5.08µm) |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) | Contact Finish - Post | Tin |
| Contact Finish - Mating | Gold |
