HS09
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HS09 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HS09 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HS09 |
|---|---|
| Manufacturer | Apex Microtechnology |
| Description | HEATSINK TO3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.868 | $4.596 | $4.326 | $4.055 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.785 | $3.515 | $3.447 | $3.38 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | HS09 | Manufacturer | Apex Microtechnology |
|---|---|---|---|
| Description | HEATSINK TO3 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10799 pcs | Data sheet | HS09 Drawing |
| Category | Fans, Thermal Management | Width | 1.290" (32.77mm) |
| Type | Board Level | Thermal Resistance @ Natural | 11.70°C/W |
| Thermal Resistance @ Forced Air Flow | 14.00°C/W @ 200 LFM | Shape | Rhombus |
| Series | Apex Precision Power® | Power Dissipation @ Temperature Rise | 7.0W @ 80°C |
| Package Cooled | TO-3 | Other Names | 598-1371 598-2030 598-2030-ND |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 12 Weeks |
| Length | 1.630" (41.40mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.750" (19.05mm) | Diameter | - |
| Detailed Description | Heat Sink TO-3 Aluminum 7.0W @ 80°C Board Level | Attachment Method | Bolt On |
