TM1PB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TM1PB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TM1PB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TM1PB |
|---|---|
| Manufacturer | Amphenol Tuchel Electronics |
| Description | CONN SWITCH PLUG 1/4" |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.202 | $3.822 | $3.726 | $3.439 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.248 | $2.962 | $2.771 | $2.541 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TM1PB | Manufacturer | Amphenol Tuchel Electronics |
|---|---|---|---|
| Description | CONN SWITCH PLUG 1/4" | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 14381 pcs | Data sheet | TM1PB Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | - | Termination | Solder Cup |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Unshielded |
| Series | T | Panel Hole Size | - |
| Packaging | Bulk | Other Names | 889-1878 |
| Operating Temperature | -25°C ~ 75°C | Number of Positions/Contacts | 3 Conductors, 3 Contacts |
| Mounting Type | Free Hanging (In-Line) | Mating Length/Depth | 1.190" (30.30mm) |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Internal Switch(s) | Does Not Contain Switch | Insulation Color | - |
| Industry Recognized Mating Diameter | 6.35mm (0.250", 1/4") - Headphone | Includes | 4 pcs - 1 Connector, 2 pc Cover, 1 Strain Relief |
| Housing Material | Zinc Alloy | Gender | Male |
| Features | - | Detailed Description | 6.35mm (0.250", 1/4") - Headphone Phone Plug Stereo (3 Conductor, TRS) Connector Solder Cup |
| Current Rating | 10A | Contact Material - Plating | Nickel |
| Contact Material | Brass | Connector Type | Phone Plug |
| Cable Opening | - | Body Material | - |
| Body Color | Silver | Actual Diameter | - |
