SF1521-60107
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SF1521-60107 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SF1521-60107 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SF1521-60107 |
|---|---|
| Manufacturer | Amphenol SV Microwave |
| Description | CONN 2.92MM JACK 50OHM EDGE MNT |
| Lead Free Status / RoHS Status |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $35.865 | $33.755 | $32.70 | $30.591 | $28.903 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | SF1521-60107 | Manufacturer | Amphenol SV Microwave |
|---|---|---|---|
| Description | CONN 2.92MM JACK 50OHM EDGE MNT | Lead Free Status / RoHS Status | |
| Quantity Available | 1289 pcs | Data sheet | Solderless Edge Launch DatasheetSF1521-60107 Drawing |
| Category | Connectors, Interconnects | Shield Termination | Screw |
| Series | - | Packaging | Bulk |
| Operating Temperature | -65°C ~ 165°C | Mounting Type | Board Edge, End Launch |
| Mounting Feature | - | Moisture Sensitivity Level (MSL) | Not Applicable |
| Mating Cycles | 500 | Manufacturer Standard Lead Time | 10 Weeks |
| Insertion Loss | - | Ingress Protection | - |
| Includes | 3 pcs - 1 Connector, 2 Screws | Impedance | 50 Ohm |
| Housing Color | Silver | Frequency - Max | 40GHz |
| Features | Mounting Hardware | Fastening Type | Threaded |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Detailed Description | 2.92mm Connector Jack, Female Socket 50 Ohm Board Edge, End Launch Compression |
| Contact Termination | Compression | Connector Type | Jack, Female Socket |
| Connector Style | 2.92mm | Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper | Cable Group | - |
| Body Material | Stainless Steel | Body Finish | - |
