1214-4001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1214-4001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1214-4001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1214-4001 |
|---|---|
| Manufacturer | Amphenol SV Microwave |
| Description | CONN SMP JACK R/A 50OHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $10.112 | $9.128 | $8.746 | $8.199 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $7.926 | $7.489 | $7.27 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1214-4001 | Manufacturer | Amphenol SV Microwave |
|---|---|---|---|
| Description | CONN SMP JACK R/A 50OHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5101 pcs | Data sheet | 1214-4001 Drawing |
| Category | Connectors, Interconnects | Shield Termination | Solder |
| Series | - | Packaging | Bulk |
| Operating Temperature | - | Number of Ports | 1 |
| Mounting Type | Surface Mount, Right Angle | Mounting Feature | - |
| Mating Cycles | - | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Ingress Protection | - | Includes | - |
| Impedance | 50 Ohm | Housing Color | Gold |
| Frequency - Max | 26.5GHz | Features | EMI Ring |
| Fastening Type | Snap-On | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | SMP Connector Jack, Female Socket 50 Ohm Surface Mount, Right Angle Solder | Contact Termination | Solder |
| Connector Type | Jack, Female Socket | Connector Style | SMP |
| Center Contact Plating | Gold | Center Contact Material | Beryllium Copper |
| Cable Group | RG-405 (.086 Semi Rigid) | Body Material | Beryllium Copper |
| Body Finish | Gold |
