CB-04PMFS-QC8001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CB-04PMFS-QC8001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CB-04PMFS-QC8001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CB-04PMFS-QC8001 |
|---|---|
| Manufacturer | Amphenol LTW |
| Description | CONN RCPT FMALE 4POS SOLDER CUP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.609 | $2.502 | $2.284 | $2.175 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.067 | $1.849 | $1.74 | $1.523 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CB-04PMFS-QC8001 | Manufacturer | Amphenol LTW |
|---|---|---|---|
| Description | CONN RCPT FMALE 4POS SOLDER CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 23435 pcs | Data sheet | CB-04PMFS-QC8001 Drawing |
| Category | Connectors, Interconnects | Termination | Solder Cup |
| Shell Size, MIL | - | Shell Size - Insert | C |
| Shell Material | Polyamide (PA), Nylon, Glass Filled | Shell Finish | - |
| Series | X-Lok | Packaging | Tray |
| Other Names | 1754-1164 | Orientation | Keyed |
| Operating Temperature | -20°C ~ 80°C | Number of Positions | 4 (Data) |
| Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Front Side Nut |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 6 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP68 - Dust Tight, Waterproof |
| Features | - | Fastening Type | Push-Pull |
| Detailed Description | 4 (Data) Position Circular Connector Receptacle, Female Sockets Solder Cup Gold | Current Rating | 10A |
| Contact Finish - Mating | Gold | Connector Type | Receptacle, Female Sockets |
