FA1-NBSJ-C01-6
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FA1-NBSJ-C01-6 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FA1-NBSJ-C01-6 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FA1-NBSJ-C01-6 |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN FAKRA JACK STR 50 OHM CRIMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.108 | $1.062 | $0.973 | $0.929 | $0.885 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.774 | $0.752 | $0.641 | $0.597 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | FA1-NBSJ-C01-6 | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN FAKRA JACK STR 50 OHM CRIMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 59148 pcs | Data sheet | FAKRA SMB Connector CatalogFA1-NxSJ-C01-6 Drawing |
| Category | Connectors, Interconnects | Shield Termination | Crimp |
| Series | - | Packaging | Tray |
| Other Names | ARF1288 FA1NBSJC016 |
Operating Temperature | -40°C ~ 100°C |
| Number of Ports | 1 | Mounting Type | Free Hanging (In-Line) |
| Mounting Feature | - | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Cycles | 100 | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 0.3dB |
| Ingress Protection | - | Includes | 5 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Housing, 1 Locking Clip |
| Impedance | 50 Ohm | Housing Color | Cream |
| Frequency - Max | 6GHz | Features | Code B |
| Fastening Type | Latch Lock | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | SMB, Fakra Connector Jack, Female Socket 50 Ohm Free Hanging (In-Line) Crimp | Contact Termination | Crimp |
| Connector Type | Jack, Female Socket | Connector Style | SMB, Fakra |
| Center Contact Plating | Gold | Center Contact Material | Beryllium Copper |
| Cable Group | RG-174, 188, 188A, 316, LMR-100, M17/119-RG174 | Body Material | Brass |
| Body Finish | Nickel |
