919-136P-71AX
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 919-136P-71AX with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 919-136P-71AX with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 919-136P-71AX |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN MCX PLUG R/A 75 OHM SOLDER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 100 pcs | ||||
|---|---|---|---|---|---|
| $3.386 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 919-136P-71AX | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN MCX PLUG R/A 75 OHM SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11454 pcs | Data sheet | 919-136P-71AX DrawingAssembly Instr C77 |
| Category | Connectors, Interconnects | Shield Termination | Crimp |
| Series | - | Packaging | Bulk |
| Other Names | 919136P71AX | Operating Temperature | -65°C ~ 165°C |
| Number of Ports | 1 | Mounting Type | Free Hanging (In-Line), Right Angle |
| Mounting Feature | - | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Cycles | 500 | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 0.15dB |
| Ingress Protection | - | Includes | 4 pcs - 1 Connector, 1 End Cap, 1 Ferrule, 1 Insulator |
| Impedance | 75 Ohm | Housing Color | Gold |
| Frequency - Max | 6GHz | Features | - |
| Fastening Type | Snap-On | Dielectric Material | Polyoxymethylene (POM) Acetal, Polytetrafluoroethylene (PTFE) |
| Detailed Description | MCX Connector Plug, Male Pin 75 Ohm Free Hanging (In-Line), Right Angle Solder | Contact Termination | Solder |
| Connector Type | Plug, Male Pin | Connector Style | MCX |
| Center Contact Plating | Gold | Center Contact Material | Brass |
| Cable Group | RG-179, 179A, 179B, 187, 187A, Belden 9221, M17/94-RG179 | Body Material | Brass |
| Body Finish | Gold |
