272292
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 272292 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 272292 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 272292 |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN ADAPT JACK TO PLUG 7/16 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $24.381 | $22.947 | $22.23 | $20.795 | $19.648 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 272292 | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN ADAPT JACK TO PLUG 7/16 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1699 pcs | Data sheet | 272292 Drawing |
| Category | Connectors, Interconnects | Style | Straight |
| Series | - | Packaging | Bulk |
| Other Names | ACX2135 | Operating Temperature | -55°C ~ 155°C |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 9 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | 0.1dB | Ingress Protection | IP67 - Dust Tight, Waterproof |
| Includes | - | Impedance | 50 Ohm |
| Frequency - Max | 6GHz | Features | Low PIM |
| Fastening Type | Threaded, Threaded | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | Adapter Coaxial Connector 7/16 Jack, Female Socket To 7/16 Plug, Male Pin 50 Ohm | Convert To (Adapter End) | 7/16 Plug, Male Pin |
| Convert From (Adapter End) | 7/16 Jack, Female Socket | Conversion Type | Same Series |
| Center Gender | Female to Male | Center Contact Plating | Silver |
| Center Contact Material | Brass | Body Material | Brass |
| Body Finish | White Bronze | Adapter Type | Plug to Jack |
| Adapter Series | 7/16 DIN to 7/16 DIN |
