182306
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 182306 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 182306 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 182306 |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN UHF JACK STR SOLDER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $2.298 | $2.20 | $2.009 | $1.913 | $1.818 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.626 | $1.531 | $1.339 | $1.272 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 182306 | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN UHF JACK STR SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 29511 pcs | Data sheet | 182306 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 500V |
| Shield Termination | Crimp | Series | - |
| Packaging | Bulk | Other Names | ACX1518 |
| Operating Temperature | - | Number of Ports | 1 |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 9 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | - |
| Includes | 2 pcs - 1 Connector, 1 Ferrule | Impedance | Non-Constant |
| Housing Color | Silver | Frequency - Max | 300MHz |
| Features | - | Fastening Type | Threaded |
| Dielectric Material | Polyoxymethylene (POM) Acetal | Detailed Description | UHF Connector Jack, Female Socket Non-Constant Free Hanging (In-Line) Solder |
| Contact Termination | Solder | Connector Type | Jack, Female Socket |
| Connector Style | UHF | Center Contact Plating | Gold |
| Center Contact Material | Brass | Cable Group | RG-58, 58A, 58B, 58C, 141, 303, LMR-195, Belden B7806A, 9907 |
| Body Material | Brass | Body Finish | Nickel |
