031-70549-12G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 031-70549-12G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 031-70549-12G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 031-70549-12G |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN BNC RA PLUG 75OHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $7.039 | $6.534 | $5.864 | $5.697 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $5.026 | $4.691 | $4.591 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 031-70549-12G | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN BNC RA PLUG 75OHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6691 pcs | Data sheet | 031-70549-12G Drawing |
| Category | Connectors, Interconnects | Shield Termination | Crimp |
| Series | - | Packaging | Bulk |
| Other Names | ARF3136 | Operating Temperature | -40°C ~ 85°C |
| Number of Ports | 1 | Mounting Type | Free Hanging (In-Line), Right Angle |
| Mounting Feature | - | Moisture Sensitivity Level (MSL) | Not Applicable |
| Mating Cycles | 500 | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Ingress Protection | IP67 - Dust Tight, Waterproof | Includes | - |
| Impedance | 75 Ohm | Housing Color | Silver |
| Frequency - Max | 18GHz | Features | - |
| Fastening Type | Bayonet Lock | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | BNC Connector Plug, Male Pin 75 Ohm Free Hanging (In-Line), Right Angle Crimp | Contact Termination | Crimp |
| Connector Type | Plug, Male Pin | Connector Style | BNC |
| Center Contact Plating | Gold | Center Contact Material | Brass |
| Cable Group | Belden 4855R | Body Material | Brass |
| Body Finish | Nickel |
