MDBE09PE760
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MDBE09PE760 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MDBE09PE760 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MDBE09PE760 |
|---|---|
| Manufacturer | Amphenol Commercial Products |
| Description | CONN DSUB PLUG 9POS PNL MNT SLDR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 48 pcs | 96 pcs | |
|---|---|---|---|---|---|
| $5.715 | $5.195 | $5.065 | $4.675 | ||
| 144 pcs | 288 pcs | 528 pcs | 1008 pcs | ||
| $4.416 | $4.026 | $3.766 | $3.455 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | MDBE09PE760 | Manufacturer | Amphenol Commercial Products |
|---|---|---|---|
| Description | CONN DSUB PLUG 9POS PNL MNT SLDR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10241 pcs | Data sheet | Harsh Environment Connector CatalogMDBE09PE76x DrawingMDB Product Spec |
| Category | Connectors, Interconnects | Wire Gauge | - |
| Voltage Rating | 125V | Termination | Solder |
| Shell Size, Connector Layout | 1 (DE, E) | Shell Material, Finish | Zinc, Nickel Plated |
| Series | MDB | Packaging | Tray |
| Operating Temperature | -40°C ~ 105°C | Number of Rows | 2 |
| Number of Positions | 9 | Mounting Type | Panel Mount, Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 9 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | IP67 - Dust Tight, Waterproof | Housing Material | Thermoplastic |
| Flange Feature | Housing/Shell (Unthreaded) | Features | Board Guide, Dust Cap |
| Detailed Description | 9 Position D-Sub Plug, Male Pins Connector | Current Rating | 5A |
| Contact Type | Signal | Contact Material | Copper Alloy |
| Contact Form | - | Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Finish | Gold | Connector Type | Plug, Male Pins |
| Connector Style | D-Sub | Color | Black |
| Backset Spacing | - |
