L77TWB13W3S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy L77TWB13W3S with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy L77TWB13W3S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | L77TWB13W3S |
|---|---|
| Manufacturer | Amphenol Commercial Products |
| Description | CONN D-SUB RCPT 13P STR SLDR CUP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.618 | $3.29 | $3.207 | $2.961 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.796 | $2.55 | $2.385 | $2.376 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | L77TWB13W3S | Manufacturer | Amphenol Commercial Products |
|---|---|---|---|
| Description | CONN D-SUB RCPT 13P STR SLDR CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 12624 pcs | Data sheet | L77TWB13W3S Drawing |
| Category | Connectors, Interconnects | Wire Gauge | - |
| Voltage Rating | 300V | Termination | Solder Cup |
| Shell Size, Connector Layout | 3 (DB, B) - 13C3, 13W3 | Shell Material, Finish | Steel, Tin Plated |
| Series | TW | Packaging | Bulk |
| Operating Temperature | -55°C ~ 155°C | Number of Rows | 2 |
| Number of Positions | 13 (10 + 3 Coax or Power) | Mounting Type | Panel Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | - |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Housing Material | Thermoplastic, Glass Filled |
| Flange Feature | Housing/Shell (Unthreaded) | Features | - |
| Detailed Description | 13 (10 + 3 Coax or Power) Position D-Sub, Combo Receptacle, Female Sockets Connector | Current Rating | 7.5A |
| Contact Type | Signal and Coax or Power (Not Included) | Contact Material | Bronze |
| Contact Form | Machined | Contact Finish Thickness | 16.0µin (0.41µm) |
| Contact Finish | Gold | Connector Type | Receptacle, Female Sockets |
| Connector Style | D-Sub, Combo | Color | Black |
| Backset Spacing | - |
