17EHD015PAM000
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 17EHD015PAM000 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 17EHD015PAM000 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 17EHD015PAM000 |
|---|---|
| Manufacturer | Amphenol Commercial Products |
| Description | CONN D-SUB HD PLUG 15POS STR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.374 | $1.318 | $1.208 | $1.153 | $1.098 | |
| 250 pcs | 500 pcs | 1000 pcs | 3000 pcs | ||
| $0.961 | $0.933 | $0.796 | $0.793 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 17EHD015PAM000 | Manufacturer | Amphenol Commercial Products |
|---|---|---|---|
| Description | CONN D-SUB HD PLUG 15POS STR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 42549 pcs | Data sheet | 17EHD015Pyyyy00 Drawing |
| Category | Connectors, Interconnects | Wire Gauge | - |
| Voltage Rating | 125V | Termination | Solder Cup |
| Shell Size, Connector Layout | 1 (DE, E) High Density | Shell Material, Finish | Steel, Nickel Plated |
| Series | 17EHD | Packaging | Tray |
| Operating Temperature | -55°C ~ 105°C | Number of Rows | 3 |
| Number of Positions | 15 | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Housing Material | Polyamide (PA), Nylon, Glass Filled |
| Flange Feature | Housing/Shell (Unthreaded) | Features | Grounding Indents |
| Detailed Description | 15 Position D-Sub, High Density Plug, Male Pins Connector | Current Rating | 3A |
| Contact Type | Signal | Contact Material | Copper Alloy |
| Contact Form | Stamped | Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Finish | Gold | Connector Type | Plug, Male Pins |
| Connector Style | D-Sub, High Density | Color | Black |
| Backset Spacing | - |
