10076209-101LF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 10076209-101LF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 10076209-101LF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 10076209-101LF |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | CONN RCPT 6PR 12IMLA R/A 1.8MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $10.669 | $9.632 | $9.229 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $8.652 | $8.363 | $7.902 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 10076209-101LF | Manufacturer | Amphenol FCI |
|---|---|---|---|
| Description | CONN RCPT 6PR 12IMLA R/A 1.8MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4808 pcs | Data sheet | 10076209 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Press-Fit | Series | ZipLine™ |
| Pitch | 0.071" (1.80mm) | Packaging | Bulk |
| Other Names | 10076209101LF 609-3138 |
Operating Temperature | - |
| Number of Rows | 18 | Number of Positions Loaded | All |
| Number of Positions | 216 | Number of Columns | 12 |
| Mounting Type | Board Edge, Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 15 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Current Rating | - | Contact Layout, Typical | 72 Signal Pairs, 72 Ground |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold or Gold, GXT™ |
| Connector Usage | Backplane, Orthogonal | Connector Type | Receptacle, Female Sockets |
| Connector Style | High Density (HDC, HDI, HPC) | Color | Black |
