ACS780LLRTR-050B-T
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ACS780LLRTR-050B-T with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ACS780LLRTR-050B-T with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ACS780LLRTR-050B-T |
|---|---|
| Manufacturer | Allegro MicroSystems, LLC. |
| Description | HIGH-PRECISION LINEAR HALL-EFFEC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $2.02 | $1.781 | $1.574 | $1.277 | ||
| 50 pcs | 100 pcs | 500 pcs | 1000 pcs | ||
| $1.128 | $1.098 | $0.92 | $0.861 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | ACS780LLRTR-050B-T | Manufacturer | Allegro MicroSystems, LLC. |
|---|---|---|---|
| Description | HIGH-PRECISION LINEAR HALL-EFFEC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 40123 pcs | Data sheet | ACS780xLR |
| Category | Sensors, Transducers | Voltage - Supply | 4.5 V ~ 5.5 V |
| Series | Automotive, AEC-Q100 | Sensor Type | Hall Effect, Differential |
| Sensitivity | 40mV/A | Response Time | 3.6µs |
| Polarization | Bidirectional | Packaging | Cut Tape (CT) |
| Package / Case | 7-PowerSMD Module | Output | Ratiometric, Voltage |
| Other Names | 620-1817-1 | Operating Temperature | -40°C ~ 150°C |
| Number of Channels | 1 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 19 Weeks |
| Linearity | ±1% | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency | DC ~ 120kHz | For Measuring | AC/DC |
| Detailed Description | Current Sensor 50A 1 Channel Hall Effect, Differential Bidirectional 7-PowerSMD Module | Current - Supply (Max) | 15mA |
| Current - Sensing | 50A | Accuracy | ±1.5% |
