SWT-0.85-680
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SWT-0.85-680 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SWT-0.85-680 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SWT-0.85-680 |
|---|---|
| Manufacturer | AlfaMag Electronics (AMGIS) |
| Description | FIXED IND 680UH 850MA 1.25 OHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 200 pcs | ||||
|---|---|---|---|---|---|
| $1.375 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SWT-0.85-680 | Manufacturer | AlfaMag Electronics (AMGIS) |
|---|---|---|---|
| Description | FIXED IND 680UH 850MA 1.25 OHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 27251 pcs | Data sheet | SW Series 50kHz |
| Category | Inductors, Coils, Chokes | Type | Toroidal |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.701" L x 0.669" W (17.80mm x 17.00mm) | Shielding | Unshielded |
| Series | SW | Ratings | - |
| Q @ Freq | - | Packaging | Tray |
| Package / Case | Radial | Other Names | SWT0.85680 TE2021 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Iron Powder |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 10kHz | Inductance | 680µH |
| Height - Seated (Max) | 0.422" (10.71mm) | Frequency - Self Resonant | - |
| Detailed Description | 680µH Unshielded Toroidal Inductor 850mA 1.25 Ohm Max Radial | DC Resistance (DCR) | 1.25 Ohm Max |
| Current Rating | 850mA | Current - Saturation | - |
