SH150T-1.54-77
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SH150T-1.54-77 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SH150T-1.54-77 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SH150T-1.54-77 |
|---|---|
| Manufacturer | AlfaMag Electronics (AMGIS) |
| Description | FIXED IND 77UH 1.54A 200 MOHM TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 200 pcs | ||
|---|---|---|---|---|---|
| $2.408 | $2.188 | $1.488 | |||
| 600 pcs | 1000 pcs | 2600 pcs | |||
| $1.356 | $1.269 | $1.225 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | SH150T-1.54-77 | Manufacturer | AlfaMag Electronics (AMGIS) |
|---|---|---|---|
| Description | FIXED IND 77UH 1.54A 200 MOHM TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 30432 pcs | Data sheet | SH150 Series |
| Category | Inductors, Coils, Chokes | Type | Toroidal |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.614" L x 0.591" W (15.60mm x 15.00mm) | Shielding | Unshielded |
| Series | SH150 | Ratings | - |
| Q @ Freq | - | Packaging | Tray |
| Package / Case | Radial | Other Names | SH150T15477 TE2168 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Iron Powder |
| Manufacturer Standard Lead Time | 18 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 10kHz | Inductance | 77µH |
| Height - Seated (Max) | 0.358" (9.10mm) | Frequency - Self Resonant | - |
| Detailed Description | 77µH Unshielded Toroidal Inductor 1.54A 200 mOhm Radial | DC Resistance (DCR) | 200 mOhm |
| Current Rating | 1.54A | Current - Saturation | - |
