CT-1010
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CT-1010 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CT-1010 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CT-1010 |
|---|---|
| Manufacturer | AlfaMag Electronics (AMGIS) |
| Description | CURR SENSE XFMR 10A T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.482 | $1.887 | $1.837 | $1.689 | ||
| 100 pcs | 300 pcs | 500 pcs | 1000 pcs | ||
| $1.589 | $1.54 | $1.49 | $1.44 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CT-1010 | Manufacturer | AlfaMag Electronics (AMGIS) |
|---|---|---|---|
| Description | CURR SENSE XFMR 10A T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 23013 pcs | Data sheet | CT Series BrochureCT1010 Datasheet |
| Category | Transformers | Weight | 0.037 lb (16.78g) |
| Type | Non-Invasive (Solid Core) | Turns Ratio - Primary:Secondary | - |
| Termination Style | PC Pin | Size / Dimension | 0.937" L x 0.438" W (23.80mm x 11.12mm) |
| Series | CT | Ratings | - |
| Packaging | Tray | Other Names | CT1010 TE2274 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 0.937" (23.80mm) | Frequency Range | 50/60Hz |
| Energy Time (E.T.) | - | Detailed Description | 10A Current Sense Transformer 50/60Hz 41.8 Ohm Through Hole |
| DC Resistance (DCR) | 41.8 Ohm | Current Ratio | 1000:1 |
| Current Rating | 10A |
