XT314524
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy XT314524 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy XT314524 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | XT314524 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY GEN PURPOSE SPDT 16A 24V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 30 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.45 | $2.297 | $2.042 | $1.94 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.838 | $1.634 | $1.531 | $1.429 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | XT314524 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPDT 16A 24V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 22654 pcs | Data sheet | XT Product BrochureXT Series |
| Category | Relays | Turn On Voltage (Max) | 18 VAC |
| Turn Off Voltage (Min) | 3.6 VAC | Termination Style | Plug In |
| Switching Voltage | 400VAC - Max | Series | XT, SCHRACK |
| Release Time | 6ms | Relay Type | General Purpose |
| Packaging | Tube | Other Names | 1887101-3 PB1189 |
| Operating Temperature | -40°C ~ 70°C | Operate Time | 9ms |
| Mounting Type | Socketable | Manufacturer Standard Lead Time | 23 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Insulation - Class F |
| Detailed Description | General Purpose Relay SPDT (1 Form C) 24VAC Coil Socketable | Contact Rating (Current) | 16A |
| Contact Material | Silver Nickel (AgNi) | Contact Form | SPDT (1 Form C) |
| Coil Voltage | 24VAC | Coil Type | Non Latching |
| Coil Resistance | 350 Ohms | Coil Power | 0.6 VA |
| Coil Current | 31.6mA |
