T9AS5D22-24
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy T9AS5D22-24 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy T9AS5D22-24 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | T9AS5D22-24 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY GEN PURPOSE SPDT 20A 24V |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $2.443 | $2.291 | $2.036 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $1.934 | $1.832 | $1.693 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | T9AS5D22-24 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPDT 20A 24V | Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Quantity Available | 18504 pcs | Data sheet | T9A Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 18 VDC |
| Turn Off Voltage (Min) | 2.4 VDC | Termination Style | PC Pin, Quick Connect - 0.250" (6.3mm) |
| Switching Voltage | 277VAC - Max | Series | T9A |
| Release Time | 15ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | 3-1419104-6 PB309 T9AS5D2224 |
| Operating Temperature | -55°C ~ 85°C | Operate Time | 15ms |
| Mounting Type | Through Hole | Manufacturer Standard Lead Time | 20 Weeks |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant | Features | Insulation - Class F, Sealed - Fully |
| Detailed Description | General Purpose Relay SPDT (1 Form C) 24VDC Coil Through Hole | Contact Rating (Current) | 20A |
| Contact Material | Silver Cadmium Oxide (AgCdO) | Contact Form | SPDT (1 Form C) |
| Coil Voltage | 24VDC | Coil Type | Non Latching |
| Coil Resistance | 576 Ohms | Coil Power | 1 W |
| Coil Current | 41.7mA |
