SGD-80-3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SGD-80-3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SGD-80-3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SGD-80-3 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | SENSOR LINEAR 3048MM CONNECTOR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $140.892 | $132.086 | $127.683 | $123.28 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SGD-80-3 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | SENSOR LINEAR 3048MM CONNECTOR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 307 pcs | Data sheet | SGD Series Datasheet |
| Category | Sensors, Transducers | Voltage - Supply | 8 V ~ 40 V |
| Termination Style | Connector | Technology | Resistive |
| Supplier Device Package | - | Series | SGD |
| Rotation Angle - Electrical, Mechanical | - | Resistance Tolerance | ±10% |
| Resistance | 10 kOhms | Packaging | Box |
| Package / Case | Module | Output Signal | - |
| Output | Analog Voltage, 4 ~ 20mA | Other Names | 223-1659 |
| Operating Temperature | -18°C ~ 70°C | Mounting Type | Custom |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 4 Weeks |
| Linearity | - | Linear Range | 0 ~ 3048mm (0 ~ 120") |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | For Measuring | Linear Position |
| Detailed Description | Resistive Sensor Linear Position String Potentiometer Connector | Actuator Type | String Potentiometer |
