S86R11A1B1D1120
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy S86R11A1B1D1120 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy S86R11A1B1D1120 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | S86R11A1B1D1120 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY GEN PURPOSE DPDT 20A 120V |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $19.845 | $18.802 | $17.757 | $16.713 | $15.668 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | S86R11A1B1D1120 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY GEN PURPOSE DPDT 20A 120V | Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Quantity Available | 2119 pcs | Data sheet | S86R, S87R Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 102 VAC |
| Turn Off Voltage (Min) | - | Termination Style | Quick Connect - 0.250" (6.3mm) |
| Switching Voltage | 277VAC - Max | Series | S86R |
| Relay Type | General Purpose | Packaging | Bulk |
| Other Names | 1393134-3 PB510 |
Operating Temperature | -10°C ~ 65°C |
| Mounting Type | Chassis Mount | Manufacturer Standard Lead Time | 18 Weeks |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant | Features | Insulation - Class B |
| Detailed Description | General Purpose Relay DPDT (2 Form C) 120VAC Coil Chassis Mount | Contact Rating (Current) | 20A |
| Contact Material | Silver Cadmium Oxide (AgCdO) | Contact Form | DPDT (2 Form C) |
| Coil Voltage | 120VAC | Coil Type | Non Latching |
| Coil Resistance | 800 Ohms | Coil Power | 4 VA |
| Coil Current | 33.0mA |
