RT424F05
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RT424F05 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RT424F05 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RT424F05 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY GENERAL PURPOSE DPDT 8A 5V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 20 pcs | 40 pcs | 60 pcs | |
|---|---|---|---|---|---|
| $2.652 | $2.486 | $2.21 | $2.099 | ||
| 100 pcs | 260 pcs | 500 pcs | 1000 pcs | ||
| $1.989 | $1.768 | $1.657 | $1.547 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | RT424F05 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY GENERAL PURPOSE DPDT 8A 5V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 25366 pcs | Data sheet | RT2 Bistable |
| Category | Relays | Turn On Voltage (Max) | 3.5 VDC |
| Turn Off Voltage (Min) | - | Termination Style | PC Pin |
| Switching Voltage | 400VAC - Max | Series | RT2 Bistable, SCHRACK |
| Release Time | 5ms | Relay Type | General Purpose |
| Packaging | Tube | Other Names | 5-1393243-2 PB2024 RT424F05-ND |
| Operating Temperature | -40°C ~ 85°C | Operate Time | 10ms |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 35 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Insulation - Class F, Sealed - Flux Protection | Detailed Description | General Purpose Relay DPDT (2 Form C) 5VDC Coil Through Hole |
| Contact Rating (Current) | 8A | Contact Material | Silver Nickel (AgNi) |
| Contact Form | DPDT (2 Form C) | Coil Voltage | 5VDC |
| Coil Type | Latching, Dual Coil | Coil Resistance | 42 Ohms |
| Coil Power | 595 mW | Coil Current | 119mA |
