LEV100A5ANG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LEV100A5ANG with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy LEV100A5ANG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | LEV100A5ANG |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY CONTACTOR SPST 100A 24V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $34.956 | $33.015 | $31.073 | $29.131 | $27.189 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | LEV100A5ANG | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY CONTACTOR SPST 100A 24V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1398 pcs | Data sheet | LEV100 Series |
| Category | Relays | Turn On Voltage (Max) | 16 VDC |
| Turn Off Voltage (Min) | 2.4 VDC | Termination Style | Stud |
| Switching Voltage | 900VDC - Max | Series | LEV100, KILOVAC |
| Release Time | 10ms | Packaging | Bulk |
| Other Names | 9-1618389-8 A101164 LEV100A5ANG-ND |
Operating Temperature | -40°C ~ 85°C |
| Operate Time | 25ms | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 7 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Sealed - Hermetically |
| Contact Rating (Current) | 100A | Contact Material | - |
| Contact Form | SPST-NO (DM) (1 Form X) | Coil Voltage | 24VDC |
| Coil Resistance | 96 Ohms | Coil Power | 6 W |
| Coil Current | 250mA |
