HD10-5-16P
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HD10-5-16P with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HD10-5-16P with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HD10-5-16P |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN RCPT HSNG MALE 5POS PNL MNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.648 | $2.537 | $2.316 | $2.206 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.096 | $1.875 | $1.765 | $1.544 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | HD10-5-16P | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN RCPT HSNG MALE 5POS PNL MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 20280 pcs | Data sheet | HD10-5-16P Drawing |
| Category | Connectors, Interconnects | Type | For Male Pins |
| Shielding | Unshielded | Shell Size, MIL | - |
| Shell Size - Insert | 5-16 | Shell Material | Polyamide (PA), Nylon, Glass Filled |
| Shell Finish | - | Series | HD10 |
| Packaging | Bulk | Other Names | 1734-1309 |
| Orientation | Keyed | Operating Temperature | -40°C ~ 125°C |
| Number of Positions | 5 | Note | Contacts Not Included |
| Mounting Type | Panel Mount | Mounting Feature | Flange |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Flammability Rating | UL94 V-1 |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insert Material | Polyamide (PA), Nylon, Glass Filled | Ingress Protection | IP68 - Dust Tight, Waterproof |
| Includes | - | Housing Color | Gray |
| Features | - | Fastening Type | Bayonet Lock |
| Detailed Description | 5 Position Circular Connector Receptacle Housing Panel Mount | Coupling Nut Material, Plating | - |
| Coupling Nut Diameter | - | Contact Type | Crimp |
| Contact Size | 16 | Contact Shape | Circular |
| Connector Type | Receptacle Housing |
