FW1109G06
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FW1109G06 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FW1109G06 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FW1109G06 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY GEN PURPOSE DPDT 2A 28V |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $58.954 | $55.271 | $51.586 | $49.744 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | FW1109G06 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY GEN PURPOSE DPDT 2A 28V | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 778 pcs | Data sheet | FW, FW5A, SF, SF5A Series Relays |
| Category | Relays | Turn On Voltage (Max) | 13.5 VDC |
| Turn Off Voltage (Min) | - | Termination Style | Solder Hook |
| Switching Voltage | 28VDC - Nom | Series | Military, MIL-R-5757/10, FW, CII |
| Release Time | 5ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | 1122-1125 1122-1125-MIL 1122-1125-ND 2-1617019-3 A101687 A101687-ND A132187 FW1109G06-ND M5757/10-035 |
| Operating Temperature | -65°C ~ 125°C | Operate Time | 5ms |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 21 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Features | - | Detailed Description | General Purpose Relay DPDT (2 Form C) Chassis Mount |
| Contact Rating (Current) | 2A | Contact Material | - |
| Contact Form | DPDT (2 Form C) | Coil Voltage | 26.5VDC |
| Coil Type | Non Latching | Coil Resistance | 675 Ohms |
| Coil Power | - |
