84501-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 84501-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 84501-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 84501-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN FFC VERT 12POS 2.54MM PCB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 10400 pcs | ||||
|---|---|---|---|---|---|
| $0.169 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 84501-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN FFC VERT 12POS 2.54MM PCB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 137624 pcs | Data sheet | 84501-1 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder | Series | - |
| Pitch | 0.100" (2.54mm) | Packaging | Tube |
| Other Names | 845011 A109513 |
Operating Temperature | - |
| Number of Positions | 12 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | - |
| Material Flammability Rating | - | Locking Feature | Slide Lock |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Housing Material | Thermoplastic |
| Housing Color | - | Height Above Board | 0.310" (7.87mm) |
| Flat Flex Type | FFC | Features | Zero Insertion Force (ZIF) |
| FFC, FCB Thickness | - | Detailed Description | 12 Position FFC Connector Contacts, Vertical, 1 Sided 0.100" (2.54mm) Through Hole |
| Current Rating | - | Contact Material | - |
| Contact Finish Thickness | 150.0µin (3.81µm) | Contact Finish | Tin |
| Connector/Contact Type | Contacts, Vertical, 1 Sided | Cable End Type | - |
| Actuator Material | Thermoplastic | Actuator Color | - |
