8-34294-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 8-34294-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 8-34294-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 8-34294-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN TERM RECT TONG 16-22 AWG |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.60 | $0.544 | $0.511 | $0.489 | $0.466 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.422 | $0.389 | $0.333 | $0.311 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 8-34294-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN TERM RECT TONG 16-22 AWG | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 75547 pcs | Data sheet | 34294 |
| Category | Connectors, Interconnects | Wire Gauge | 16-22 AWG |
| Width - Outer Edges | 0.140" (3.56mm) | Termination | Crimp |
| Terminal Type | Rectangular Tongue | Terminal Style | No Stud Hole |
| Tab Thickness | 0.031" (0.79mm) | Stud/Tab Size | - |
| Series | PIDG | Packaging | Bulk |
| Other Names | 8-34294-1-ND A136796 |
Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 18 Weeks |
| Length - Overall | 0.904" (22.96mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation | Insulated | Features | Serrated Termination |
| Diameter - Ring ID | - | Diameter - Barrel OD | - |
| Diameter - Barrel ID | - | Detailed Description | Terminal Connector Rectangular Rectangular Tongue 16-22 AWG |
| Contact Material | Copper | Contact Finish | Tin |
| Color | Red |
