770997-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 770997-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 770997-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 770997-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | PC BOARD VERTICAL SOCKET HEADERS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $0.857 | $0.777 | $0.666 | |||
| 500 pcs | 1000 pcs | 5000 pcs | |||
| $0.555 | $0.475 | $0.422 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 770997-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | PC BOARD VERTICAL SOCKET HEADERS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 85643 pcs | Data sheet | 770997 |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder | Style | Board to Cable/Wire |
| Series | Commercial MATE-N-LOK | Row Spacing - Mating | - |
| Pitch - Mating | 0.200" (5.08mm) | Packaging | Bulk |
| Other Names | 7709971 | Operating Temperature | - |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 4 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-2 |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polyamide (PA), Nylon |
| Insulation Height | 0.455" (11.56mm) | Insulation Color | Natural |
| Ingress Protection | - | Features | - |
| Fastening Type | Detent Lock | Detailed Description | 4 Position Header Connector 0.200" (5.08mm) Through Hole Tin |
| Current Rating | - | Contact Type | Female Socket |
| Contact Shape | Circular | Contact Material | Phosphor Bronze |
| Contact Length - Post | 0.170" (4.32mm) | Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | - | Contact Finish - Post | Tin |
| Contact Finish - Mating | Tin | Connector Type | Header |
| Applications | - |
