558503-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 558503-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 558503-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 558503-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN MOD JACK 8P8C R/A SHIELDED |
| Lead Free Status / RoHS Status | Lead free / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 558503-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN MOD JACK 8P8C R/A SHIELDED | Lead Free Status / RoHS Status | Lead free / RoHS non-compliant |
| Quantity Available | 5745 pcs | Data sheet | 558503 |
| Category | Connectors, Interconnects | Termination | Solder |
| Tab Direction | Down | Shielding | Shielded |
| Series | - | Ratings | Cat5 |
| Packaging | Tray | Other Names | A9097 |
| Orientation | 90° Angle (Right) | Operating Temperature | -40°C ~ 85°C |
| Number of Rows | 1 | Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
| Number of Ports | 4 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS non-compliant |
| LED Color | Does Not Contain LED | Ingress Protection | - |
| Housing Material | Polycyclohexylenedimethylene Terephthalate (PCT) | Features | Board Guide |
| Detailed Description | Jack Modular Connector 8p8c (RJ45, Ethernet) 90° Angle (Right) Shielded Cat5 | Contact Material | Phosphor Bronze |
| Contact Finish Thickness | 50.0µin (1.27µm) | Contact Finish | Gold |
| Connector Type | Jack |
