5227169-4
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 5227169-4 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 5227169-4 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 5227169-4 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN BNC RCPT STR 50 OHM SOLDER |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.585 | $1.521 | $1.394 | $1.331 | $1.267 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.109 | $1.077 | $0.919 | $0.855 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 5227169-4 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN BNC RCPT STR 50 OHM SOLDER | Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Quantity Available | 40197 pcs | Data sheet | 5227169 DrawingBNC Conn 50/75 ohm Catalog |
| Category | Connectors, Interconnects | Voltage Rating | 500V |
| Shield Termination | Solder | Series | - |
| Packaging | Bulk | Other Names | 5227169-4-ND A139207 |
| Operating Temperature | -65°C ~ 165°C | Number of Ports | 1 |
| Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Rear Side Nut |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant | Insertion Loss | - |
| Ingress Protection | - | Includes | 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut |
| Impedance | 50 Ohm | Housing Color | Silver |
| Frequency - Max | 4GHz | Features | Extended Insulation |
| Fastening Type | Bayonet Lock | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | BNC Connector Receptacle, Female Socket 50 Ohm Panel Mount Solder Cup | Contact Termination | Solder Cup |
| Connector Type | Receptacle, Female Socket | Connector Style | BNC |
| Center Contact Plating | Gold | Center Contact Material | Phosphor Bronze |
| Cable Group | - | Body Material | Zinc |
| Body Finish | Nickel |
