5145089-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 5145089-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 5145089-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 5145089-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN EDGE DUAL FMALE 24POS 0.100 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 27 pcs | 54 pcs | 108 pcs |
|---|---|---|---|---|---|
| $2.166 | $2.074 | $1.893 | $1.803 | $1.713 | |
| 270 pcs | 513 pcs | 1026 pcs | 2511 pcs | ||
| $1.533 | $1.443 | $1.262 | $1.199 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 5145089-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN EDGE DUAL FMALE 24POS 0.100 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 30031 pcs | Data sheet | Card Edge Products Catalog5145089 Drawing |
| Category | Connectors, Interconnects | Termination | Solder |
| Series | Standard Edge II | Read Out | Dual |
| Pitch | 0.100" (2.54mm) | Packaging | Tray |
| Other Names | 5145089-1-ND A115290 |
Operating Temperature | -55°C ~ 85°C |
| Number of Rows | 2 | Number of Positions/Bay/Row | - |
| Number of Positions | 24 | Mounting Type | Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Insulation | Thermoplastic |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Gender | Female | Flange Feature | - |
| Features | Board Lock | Contact Type | - |
| Contact Material | Phosphor Bronze | Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Finish | Gold | Color | Brown |
| Card Type | Non Specified - Dual Edge | Card Thickness | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) |
