5-966926-2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 5-966926-2 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 5-966926-2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 5-966926-2 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | 2X2P MODU 2MM PIN HDR,SMD, BLSTR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $0.866 | $0.785 | $0.737 | $0.705 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $0.673 | $0.609 | $0.561 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 5-966926-2 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | 2X2P MODU 2MM PIN HDR,SMD, BLSTR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 58760 pcs | Data sheet | 966926 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 250VAC |
| Termination | Solder | Style | Board to Board or Cable |
| Shrouding | Unshrouded | Series | AMPMODU |
| Row Spacing - Mating | 0.079" (2.00mm) | Pitch - Mating | 0.079" (2.00mm) |
| Packaging | Cut Tape (CT) | Overall Contact Length | - |
| Other Names | A121803CT | Operating Temperature | -40°C ~ 105°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 4 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 22 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Liquid Crystal Polymer (LCP) |
| Insulation Height | 0.035" (0.90mm) | Insulation Color | Black |
| Ingress Protection | - | Features | Pick and Place |
| Fastening Type | Push-Pull | Detailed Description | Connector Header Surface Mount 4 position 0.079" (2.00mm) |
| Current Rating | 1A | Contact Type | Male Pin |
| Contact Shape | Square | Contact Material | Brass |
| Contact Length - Post | - | Contact Length - Mating | 0.136" (3.45mm) |
| Contact Finish Thickness - Post | 98.4µin (2.50µm) | Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold |
| Connector Type | Header, Breakaway | Applications | - |
