5-1825136-9
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 5-1825136-9 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 5-1825136-9 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 5-1825136-9 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | SWITCH TOGGLE SPDT 5A 120V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.759 | $1.675 | $1.633 | $1.591 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.549 | $1.423 | $1.256 | $1.13 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 5-1825136-9 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | SWITCH TOGGLE SPDT 5A 120V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 26288 pcs | Data sheet | 1825136 Drawing |
| Category | Switches | Voltage Rating - DC | 28V |
| Voltage Rating - AC | 120V | Termination Style | Solder Lug |
| Switch Function | On-Mom | Series | Gemini A |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | Packaging | Bulk |
| Other Names | A108P3ZQ04 A108P3ZQ04-ND |
Operating Temperature | -30°C ~ 85°C |
| Mounting Type | Panel Mount | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Illumination Voltage (Nominal) | - | Illumination Type, Color | - |
| Illumination | Non-Illuminated | Features | Epoxy Sealed Terminals |
| Electrical Life | 6,000 Cycles | Detailed Description | Toggle Switch SPDT Panel Mount |
| Current Rating | 5A (AC/DC) | Circuit | SPDT |
| Bushing Thread | 1/4-40 | Actuator Type | Flatted |
| Actuator Material | Brass, Nickel Plated | Actuator Length | 12.29mm |
