34247
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 34247 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 34247 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 34247 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN SPADE TERM 22-26AWG #4 |
| Lead Free Status / RoHS Status | Not applicable / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.06 | $0.057 | $0.049 | $0.043 | $0.04 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.035 | $0.034 | $0.027 | $0.025 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 34247 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN SPADE TERM 22-26AWG #4 | Lead Free Status / RoHS Status | Not applicable / RoHS Compliant |
| Quantity Available | 885614 pcs | Data sheet | 34247 |
| Category | Connectors, Interconnects | Wire Gauge | 22-26 AWG |
| Width - Outer Edges | 0.203" (5.16mm) | Tongue Inside Opening | 0.119" (3.02mm) |
| Termination | Crimp | Terminal Type | Standard |
| Stud/Tab Size | 4 Stud | Series | Budget |
| Packaging | Bulk | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Insulation | - |
| Manufacturer Standard Lead Time | 14 Weeks | Length - Termination | 0.135" (3.43mm) |
| Length - Ring Center to Termination | 0.211" (5.36mm) | Length - Overall | 0.431" (10.95mm) |
| Lead Free Status / RoHS Status | Not applicable / RoHS Compliant | Insulation Diameter | - |
| Insulation | Non-Insulated | Features | Serrated Termination |
| Detailed Description | 4 Stud Spade Terminal Connector Crimp 22-26 AWG | Contact Material | Copper |
| Contact Finish | Tin | Color | - |
