3-6437592-9
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 3-6437592-9 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 3-6437592-9 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 3-6437592-9 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | SWITCH TOGGLE DPDT 20A 125V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $9.973 | $9.387 | $8.801 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $8.214 | $7.921 | $7.627 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 3-6437592-9 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | SWITCH TOGGLE DPDT 20A 125V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4121 pcs | Data sheet | 1968501 Drawing |
| Category | Switches | Voltage Rating - DC | 30V |
| Voltage Rating - AC | 125V | Termination Style | Quick Connect - 0.250" (6.3mm) |
| Switch Function | On-Off-On | Series | AW |
| Panel Cutout Dimensions | Circular - 12.50mm Dia | Packaging | Bulk |
| Other Names | 3-6437592-9-ND 450-2173 AWTP1504 |
Operating Temperature | -20°C ~ 70°C |
| Mounting Type | Panel Mount | Manufacturer Standard Lead Time | 17 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP67 - Dust Tight, Waterproof |
| Illumination Voltage (Nominal) | - | Illumination Type, Color | - |
| Illumination | Non-Illuminated | Features | Sealed |
| Electrical Life | 20,000 Cycles | Detailed Description | Toggle Switch DPDT Panel Mount |
| Current Rating | 20A (AC/DC) | Circuit | DPDT |
| Bushing Thread | M12 x 1 | Actuator Type | Standard Round |
| Actuator Material | Brass, Chrome Plated | Actuator Length | 17.50mm |
