Home > Products > Switches > Toggle Switches > 3-1825138-1

3-1825138-1

3-1825138-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 3-1825138-1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number 3-1825138-1
Manufacturer Agastat Relays / TE Connectivity
Description SWITCH TOGGLE DPDT 5A 120V
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 20592 pcs
Reference Price
(In US Dollars)		500 pcs
$1.457

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$1.457

Product parameter

Part Number 3-1825138-1 Manufacturer Agastat Relays / TE Connectivity
Description SWITCH TOGGLE DPDT 5A 120V Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 20592 pcs Data sheet Switches Core Program Catalog1825138 DrawingGemini Series, Quick Ref Guide
Category Switches Voltage Rating - DC 28V
Voltage Rating - AC 120V Termination Style Solder Lug
Switch Function On-On Series Gemini A
Panel Cutout Dimensions Circular - 12.00mm Dia Packaging Bulk
Other Names 450-1904
A201TZQ04
A201TZQ04-ND		 Operating Temperature -30°C ~ 85°C
Mounting Type Panel Mount Moisture Sensitivity Level (MSL) 1 (Unlimited)
Manufacturer Standard Lead Time 9 Weeks Lead Free Status / RoHS Status Lead free / RoHS Compliant
Ingress Protection - Illumination Voltage (Nominal) -
Illumination Type, Color - Illumination Non-Illuminated
Features Epoxy Sealed Terminals Electrical Life 6,000 Cycles
Detailed Description Toggle Switch DPDT Panel Mount Current Rating 5A (AC/DC)
Circuit DPDT Bushing Thread 15/32-32
Actuator Type Standard Round Actuator Material Brass, Nickel Plated
Actuator Length 17.45mm
