Home > Products > Switches > Toggle Switches > 3-1825136-7

3-1825136-7

3-1825136-7
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 3-1825136-7 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number 3-1825136-7
Manufacturer Agastat Relays / TE Connectivity
Description SWITCH TOGGLE SPDT 5A 120V
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 34113 pcs
Reference Price
(In US Dollars)		1 pcs10 pcs25 pcs50 pcs
$1.611$1.545$1.478$1.411
100 pcs250 pcs500 pcs1000 pcs
$1.276$1.176$1.075$0.94

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$1.611

Product parameter

Part Number 3-1825136-7 Manufacturer Agastat Relays / TE Connectivity
Description SWITCH TOGGLE SPDT 5A 120V Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 34113 pcs Data sheet 1825136 DrawingAE Series, 1825142 Drawing
Category Switches Voltage Rating - DC 28V
Voltage Rating - AC 120V Termination Style PC Pin
Switch Function On-On Series Gemini A
Panel Cutout Dimensions - Packaging Bulk
Other Names 3-1825136-7-ND
450-2389
A101SD9V30Q04		 Operating Temperature -30°C ~ 85°C
Mounting Type Through Hole Moisture Sensitivity Level (MSL) 1 (Unlimited)
Manufacturer Standard Lead Time 9 Weeks Lead Free Status / RoHS Status Lead free / RoHS Compliant
Ingress Protection - Illumination Voltage (Nominal) -
Illumination Type, Color - Illumination Non-Illuminated
Features Epoxy Sealed Terminals Electrical Life 6,000 Cycles
Detailed Description Toggle Switch SPDT Through Hole Current Rating 5A (AC/DC)
Circuit SPDT Bushing Thread Unthreaded
Actuator Type Standard Round Actuator Material Brass, Nickel Plated
Actuator Length 12.19mm
