2118309-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2118309-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2118309-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2118309-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RF ANT 2.4/5GHZ PCB TRACE CABLE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.009 | $0.967 | $0.887 | $0.846 | $0.806 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.705 | $0.685 | $0.584 | $0.544 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2118309-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RF ANT 2.4/5GHZ PCB TRACE CABLE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 63188 pcs | Data sheet | 2118309 Drawing2118309-1 Datasheet |
| Category | RF/IF and RFID | VSWR | 2 |
| Termination | Cable (120mm) - U.FL | Series | - |
| Return Loss | - | Power - Max | 3W |
| Packaging | Bulk | Other Names | A120528 |
| Number of Bands | 2 | Mounting Type | Adhesive |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 13 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Height (Max) | 0.102" (2.60mm) | Gain | 3.7dBi |
| Frequency Range | 2.4GHz ~ 2.483GHz, 4.9GHz ~ 5.875GHz | Frequency Group | UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz) |
| Frequency (Center/Band) | 2.4GHz, 5GHz | Features | - |
| Detailed Description | 2.4GHz, 5GHz Bluetooth, Wi-Fi, WLAN, Zigbee™ PCB Trace RF Antenna 2.4GHz ~ 2.483GHz, 4.9GHz ~ 5.875GHz 3.7dBi Cable (120mm) - U.FL Adhesive | Applications | Bluetooth, Wi-Fi, WLAN, Zigbee™ |
| Antenna Type | PCB Trace |
