2-966658-2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2-966658-2 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2-966658-2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2-966658-2 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | PIN HEADER, ASSY 2X16POS. |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $0.912 | $0.827 | $0.709 | |||
| 500 pcs | 1000 pcs | 5000 pcs | |||
| $0.591 | $0.506 | $0.449 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2-966658-2 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | PIN HEADER, ASSY 2X16POS. | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 81778 pcs | Data sheet | 966658 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 12V |
| Termination | Solder | Style | Board to Board or Cable |
| Shrouding | Shrouded - 4 Wall | Series | AMPMODU Mod II |
| Row Spacing - Mating | 0.100" (2.54mm) | Pitch - Mating | 0.100" (2.54mm) |
| Packaging | Tray | Overall Contact Length | 0.520" (13.21mm) |
| Other Names | 2-966658-2-ND A128694 |
Operating Temperature | -40°C ~ 110°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 32 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | - |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 15 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polyphthalamide (PPA), Glass Filled |
| Insulation Height | 0.795" (20.20mm) | Insulation Color | Blue |
| Ingress Protection | - | Features | Board Lock |
| Fastening Type | Latch Holder | Detailed Description | Connector Header Through Hole 32 position 0.100" (2.54mm) |
| Current Rating | - | Contact Type | Male Pin |
| Contact Shape | Square | Contact Material | Brass |
| Contact Length - Post | 0.098" (2.50mm) | Contact Length - Mating | 0.268" (6.80mm) |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | 78.7µin (2.00µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Tin |
| Connector Type | Header | Applications | Automotive |
