2-2822979-3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2-2822979-3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2-2822979-3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2-2822979-3 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN SOCKET LGA 3647POS GOLD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 12 pcs | 36 pcs | 60 pcs | 108 pcs |
|---|---|---|---|---|---|
| $19.045 | $17.924 | $17.364 | $16.243 | $15.347 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 2-2822979-3 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN SOCKET LGA 3647POS GOLD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2513 pcs | Data sheet | 2822979 Drawing |
| Category | Connectors, Interconnects | Type | LGA |
| Termination Post Length | - | Termination | Solder |
| Series | - | Pitch - Post | 0.034" (0.86mm) |
| Pitch - Mating | 0.039" (1.00mm) | Packaging | Tray |
| Other Names | A124403 | Operating Temperature | - |
| Number of Positions or Pins (Grid) | 3647 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Thermoplastic | Features | Open Frame |
| Current Rating | 500mA | Contact Resistance | - |
| Contact Material - Post | Copper Alloy | Contact Material - Mating | Copper Alloy |
| Contact Finish Thickness - Post | 30.0µin (0.76µm) | Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | Gold | Contact Finish - Mating | Gold |
