2-1825059-9
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2-1825059-9 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2-1825059-9 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2-1825059-9 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | SWITCH SLIDE DIP SPST 100MA 24V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.731 | $0.709 | $0.673 | $0.629 | $0.614 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.527 | $0.512 | $0.439 | $0.402 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2-1825059-9 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | SWITCH SLIDE DIP SPST 100MA 24V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 81586 pcs | Data sheet | 1825059 Drawing |
| Category | Switches | Washable | Yes |
| Voltage Rating | 24VDC | Termination Style | Gull Wing |
| Series | ADF | Pitch | 0.100" (2.54mm), Full |
| Packaging | Tube | Other Names | ADF06ST04 ADF06ST04-ND |
| Operating Temperature | -30°C ~ 85°C | Number of Positions | 6 |
| Mounting Type | Surface Mount | Mechanical Life | 1,000 Cycles |
| Manufacturer Standard Lead Time | 15 Weeks | Length | 0.678" (17.22mm) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height Above Board | 0.177" (4.50mm) |
| Features | Tape Seal | Electrical Life | 1,000 Cycles |
| Detailed Description | Dip Switch SPST 6 Position Surface Mount Slide (Standard) Actuator 100mA 24VDC | Current Rating | 100mA |
| Contact Material | Copper Alloy | Contact Finish | Gold |
| Circuit | SPST | Body Material | Polyphenylene Sulfide (PPS) |
| Actuator Type | Slide (Standard) | Actuator Level | Flush, Recessed |
