1775099-8
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1775099-8 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1775099-8 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1775099-8 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | ATX PWR CONN 1 BDLK 12 POS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $0.218 | $0.206 | $0.158 | $0.137 | ||
| 1000 pcs | 5000 pcs | 10000 pcs | |||
| $0.113 | $0.099 | $0.092 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1775099-8 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | ATX PWR CONN 1 BDLK 12 POS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 208184 pcs | Data sheet | 1775099 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 250VAC |
| Termination | Solder | Style | - |
| Series | ATX | Row Spacing - Mating | 0.165" (4.20mm) |
| Pitch - Mating | 0.165" (4.20mm) | Packaging | Tray |
| Other Names | 1775099-8-ND A128211 |
Operating Temperature | -25°C ~ 85°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 12 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polyamide (PA9T), Nylon 9T | Insulation Height | 0.504" (12.80mm) |
| Insulation Color | Ivory | Ingress Protection | - |
| Features | Board Lock | Fastening Type | Locking Ramp |
| Detailed Description | 12 Position Receptacle Connector 0.165" (4.20mm) Through Hole Tin | Current Rating | 9A |
| Contact Type | Female Socket | Contact Shape | Square |
| Contact Material | Brass | Contact Length - Post | 0.126" (3.20mm) |
| Contact Finish Thickness - Post | 120.0µin (3.05µm) | Contact Finish Thickness - Mating | 120.0µin (3.05µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Tin |
| Connector Type | Receptacle | Applications | - |
