1432826-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1432826-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1432826-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1432826-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY GEN PURPOSE SPDT 30A 24V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 400 pcs | ||||
|---|---|---|---|---|---|
| $1.051 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1432826-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPDT 30A 24V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 34151 pcs | Data sheet | 1432826-1 Drawing |
| Category | Relays | Turn On Voltage (Max) | 15.6 VDC |
| Turn Off Voltage (Min) | 2.4 VDC | Termination Style | Plug In, Quick Connect - 0.250" (6.3mm) |
| Switching Voltage | 14VDC - Nom | Series | VF4 |
| Release Time | 5ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | PB683 |
| Operating Temperature | -40°C ~ 85°C | Operate Time | 8ms |
| Mounting Type | Socketable | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Detailed Description | General Purpose Relay SPDT (1 Form C) 24VDC Coil Socketable | Contact Rating (Current) | 30A |
| Contact Material | Silver Tin Oxide (AgSnO) | Contact Form | SPDT (1 Form C) |
| Coil Voltage | 24VDC | Coil Type | Non Latching |
| Coil Resistance | 360 Ohms | Coil Power | - |
| Coil Current | 66.7mA |
