1059691-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1059691-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1059691-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1059691-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN MINI OSP RCPT R/A 50OHM PCB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $17.10 | $16.094 | $15.591 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $14.585 | $13.781 | $13.378 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1059691-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN MINI OSP RCPT R/A 50OHM PCB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2249 pcs | Data sheet | 1059691-1 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 335V |
| Shield Termination | Solder | Series | Blindmate |
| Packaging | Bulk | Other Names | 10596911 4565 0000 00 |
| Operating Temperature | -55°C ~ 125°C | Number of Ports | 1 |
| Mounting Type | Through Hole, Right Angle | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 5000 |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | - |
| Includes | - | Impedance | 50 Ohm |
| Housing Color | Gold | Frequency - Max | 22GHz |
| Features | - | Fastening Type | Snap-On |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Detailed Description | OSP, Mini Connector Receptacle, Male Pin 50 Ohm Through Hole, Right Angle Solder |
| Contact Termination | Solder | Connector Type | Receptacle, Male Pin |
| Connector Style | OSP, Mini | Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper | Cable Group | - |
| Body Material | Stainless Steel | Body Finish | Gold |
