1-5178203-6
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1-5178203-6 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1-5178203-6 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1-5178203-6 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN 100POS CAP ASSY |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 12 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $14.732 | $13.299 | $11.547 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1-5178203-6 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN 100POS CAP ASSY | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3337 pcs | Data sheet | 178203 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | Multi-Lock |
| Row Spacing - Mating | 0.098" (2.50mm) | Pitch - Mating | - |
| Packaging | Tube | Overall Contact Length | - |
| Other Names | A124498 | Operating Temperature | -30°C ~ 105°C |
| Number of Rows | 4 | Number of Positions Loaded | All |
| Number of Positions | 100 | Mounting Type | Board Edge, Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | - |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 18 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Insulation Height | - | Insulation Color | Gray |
| Ingress Protection | - | Features | Mounting Brackets |
| Fastening Type | Latch Holder | Detailed Description | Connector Header Board Edge, Through Hole, Right Angle 100 position |
| Current Rating | Varies by Wire Gauge | Contact Type | Tab |
| Contact Shape | Rectangular | Contact Material | Brass |
| Contact Length - Post | 0.157" (4.00mm) | Contact Length - Mating | 0.280" (7.11mm) |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin-Lead | Contact Finish - Mating | Gold |
| Connector Type | - | Applications | Automotive, General Purpose |
