| Part Number | 54548-2670 |
|---|---|
| Manufacturer | Molex Connector Corporation |
| Description | CONN FFC BOTTOM 26POS 0.50MM R/A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 54548-2670 | Manufacturer | Molex Connector Corporation |
|---|---|---|---|
| Description | CONN FFC BOTTOM 26POS 0.50MM R/A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4625 pcs | Data sheet | 54548-2670 |
| Category | Connectors, Interconnects | Voltage - DC Spark Over (Nom) | Phosphor Bronze |
| Termination | Solder | Simplex/Duplex | - |
| Series | Easy-On™ 54548 | RoHS Status | Tape & Reel (TR) |
| Plug/Mating Plug Diameter | - | Pitch - Connector | 50V |
| Other Names | 054548-2670 054548-2670-C 0545482670 0545482670-C 54548-2619 54548-2670-C 54548-2670-ND 545482670 545482670-C WM6496TR |
Operating Temperature | -20°C ~ 85°C |
| Number of Positions | 26 | Number of Conductors | 0.020" (0.50mm) |
| Mounting Type | Surface Mount, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Part Number | 54548-2670 |
| Locking Feature | 0.28mm | Height Above Board | 0.047" (1.20mm) |
| Features | Solder Retention, Zero Insertion Force (ZIF) | FFC, FCB Thickness | Contacts, Bottom |
| Expanded Description | 26 Position FFC, FPC Connector Contacts, Bottom 0.020" (0.50mm) Surface Mount, Right Angle | Description | CONN FFC BOTTOM 26POS 0.50MM R/A |
| Current Rating | 0.5A | Contact Finish Thickness | Tin Bismuth |
| Connector/Contact Type | FFC, FPC | Center Contact Finish | - |
| Cable Opening | Liquid Crystal Polymer (LCP) | Cable End Type | Flip Lock |
| Cable Diameter | 8µin (0.20µm) | Actuator Material | Straight, Tapered |
| Actuator Color | Polyphenylene Sulfide (PPS) |
