5017863091
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 5017863091 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 5017863091 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 5017863091 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN FFC VERT 30POS 0.50MM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 900 pcs | 1800 pcs | 2700 pcs | 6300 pcs | |
|---|---|---|---|---|---|
| $0.548 | $0.467 | $0.451 | $0.428 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 5017863091 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN FFC VERT 30POS 0.50MM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 92346 pcs | Data sheet | 5017863091 |
| Category | Connectors, Interconnects | Voltage Rating | 50V |
| Termination | Solder | Series | 501786 |
| Pitch | 0.020" (0.50mm) | Packaging | Tape & Reel (TR) |
| Other Names | 501786-3091 5017863091-ND WM14436TR |
Operating Temperature | -40°C ~ 85°C |
| Number of Positions | 30 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 20 |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 12 Weeks |
| Locking Feature | Slide Lock | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Liquid Crystal Polymer (LCP), Glass Filled | Housing Color | Black |
| Height Above Board | 0.234" (5.95mm) | Flat Flex Type | FFC |
| Features | Board Guide, Solder Retention | FFC, FCB Thickness | 0.30mm |
| Detailed Description | 30 Position FFC Connector Contacts, Vertical, 1 Sided 0.020" (0.50mm) Surface Mount | Current Rating | 0.5A |
| Contact Material | Phosphor Bronze | Contact Finish Thickness | 39.4µin (1.00µm) |
| Contact Finish | Gold | Connector/Contact Type | Contacts, Vertical, 1 Sided |
| Cable End Type | Notched | Actuator Material | - |
| Actuator Color | - |
