2042860001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2042860001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2042860001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2042860001 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | RF ANT CER PATCH SOLDER SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 250 pcs |
|---|---|---|---|---|---|
| $0.804 | $0.727 | $0.649 | $0.584 | $0.519 | |
| 500 pcs | 1000 pcs | 2500 pcs | 5000 pcs | ||
| $0.454 | $0.376 | $0.35 | $0.337 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2042860001 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | RF ANT CER PATCH SOLDER SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 70068 pcs | Data sheet | 2042860001 DrawingGNSS Antennas Overview |
| Category | RF/IF and RFID | VSWR | - |
| Termination | Solder | Series | * |
| Return Loss | -10dB | Packaging | Bulk |
| Other Names | 204286-0001 WM16802 |
Number of Bands | 1 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Height (Max) | 0.157" (4.00mm) |
| Gain | 5.5dBi | Frequency Group | UHF (1 GHz ~ 2 GHz) |
| Features | - | Detailed Description | Beidou, GLONASS, GPS Ceramic Patch RF Antenna 5.5dBi Solder Surface Mount |
| Applications | Beidou, GLONASS, GPS | Antenna Type | Ceramic Patch |
